Crystal 200 x 100 x 70 mm Permanent Magnetic Chucks Fine Pole (Heavy Duty), AA-15712
Roll over the image to zoom in
Key Features
- Product Type: Magnetic Chuck
- Length (mm): 200 mm
- Width (mm): 100 mm
- Height (mm): 70 mm
- Magnetic Pole Gap (mm): 9.9 mm
- Bottom Plate Length: 230 mm
ToolBuy Benefits
- Secure Payments
- Order Tracking (opens in a new tab)
₹9,228 (Incl. of all taxes)
₹7,820 + ₹1,408 GST (18%)
MRP was MRP ₹8,500
Save 8%
3 Business Days
1
–
Download Product LeafletNot available
Download Crystal CatalogueNot available
Download Crystal CatalogueNot available
Highlights
- This Permanent magnetic chuck has a steel & brass laminated top plate which gives this chuck better life & clamping power.
- The fine pole pitch of 9.9 mm enables securing of small workpieces during the grinding operation.
- Our design offers maximum holding power, ease of installation, and operation.
- Better magnetic grip due to close pole.
Please Note that Product may differ eg. colour, size from the product Image displayed on website. Kindly check the specifications provided to make better purchase decision.
Specifications
| Length (mm) | 200 mm |
|---|---|
| Width (mm) | 100 mm |
| Height (mm) | 70 mm |
| Magnetic Pole Gap (mm) | 9.9 mm |
| Bottom Plate Length | 230 mm |
| Series | AA-157 |
| Standard | IS 4816 - 1987 |
