₹20,347 (Incl. of all taxes)
₹17,243 + ₹3,104 GST (18%)
MRP was MRP ₹24,286
Save 29%
7 Business Days
1
–
| Range | ±0.9mm |
|---|---|
| Accuracy | ±0.3+3× |L|3μm, (L is measuring length in mm) |
| Repeatability | 0.15μm |
| Thermal drift | 0.25μm/°C |
| Mechanical Stroke | 2.2 mm |
| Sensor type | LVDT (full bridge) |
| Measuring Force | 0.75N |
| Protective cover | Fluorinated elastomer |
| Contact Type | Carbide |
| Insert thread | M2.5 |
| Working Environment | -10 ~ 60°C, <80% (non-condensing) |
| Storage Temperature | -20 ~ 100°C, <80% (non-condensing) |
| Cable Length | 2m (Customised from 2 - 5m) |
| Output Interface | 5-wire aviation interface |
