₹2,31,952 (Incl. of all taxes)
₹1,96,569 + ₹35,383 GST (18%)
MRP was MRP ₹3,36,163
Save 31%
3 Business Days
| Objective magnification | Magnification | Measuring Accuracy |
| 0.7X | 12X | ±9µm |
| 1X | 17X | ±9µm |
| 1.5X | 26X | ±8µm |
| 2X | 35X | ±7µm |
| 2.5X | 43X | ±7µm |
| 3X | 51X | ±7µm |
| 3.5X | 60X | ±6µm |
| 4X | 68X | ±6µm |
| 4.5X | 77X | ±5µm |
| Digital Measuring Microscope | 1 Pc |
| 1X Auxiliary Objective | 1 Pc |
| Calibration plate | 1 Pc |
| Power adapter | 1 Pc |
| Mouse | 1 Pc |
| 16G USB flash disk | 1 Pc |
| Sensor | 1/2" CMOS |
|---|---|
| Pixel | 2M |
| Resolution | 1920x1080 Pixel |
| Magnification | 12 - 77X |
| Focus distance | 60 mm |
|---|
| View field | 3.2x1.8 - 20.9x11.7 mm |
|---|
| Max workpiece height | 53 mm |
|---|
| Frame rate | 60fps |
|---|
| Output | USB/HDMI/LAN |
|---|
| Power supply | Power adapter |
|---|
| Dimensions (L x W x H) | 260 x 320 x 500 mm |
|---|
