₹7,500 (Incl. of all taxes)
₹6,356 + ₹1,144 GST (18%)
5 Business Days
| Basic Function | Range | Accuracy |
|---|---|---|
| DC Voltage | 200mV / 2V / 20V / 200V / 1000V | ±(0.05%+3) |
| AC Voltage | 200mV / 2V / 20V / 200V / 750V | ±(0.8%+80) |
| DC Current | 20mA / 200mA / 2A / 20A | ±(0.35%+10) |
| AC Current | 200mA / 2A / 20A | ±(0.8%+80) |
| Resistance | 200Ω / 2kΩ / 20kΩ / 200kΩ / 2MΩ / 20MΩ | ±(0.1%+5) |
| Frequency | 20kHz / 200kHz | ±(1.0%+20) |
| Capacitance | 20nF / 2uF / 200uF | ±(3.5%+20) |
| Display Digits | 4-1/2 Digits |
|---|---|
| Max. Display Count | 19999 Count |
| Input Impedance | 10M Ohm |
| AC Frequency Response | 3 times/s |
| Sampling Rate | 40 ~ 50kHz |
| Operation Way | Manual Range |
| Power | AC220V/110V 50Hz/60Hz |
| Dimensions (mm) | 245×220×82 mm |
