Mitutoyo 100 mm Micrometer Setting Standard, 167-104
Top Deals of the Month
Roll over the image to zoom in
Key Features
- Product Type: Micrometer Setting Standard
- Length (mm): 100 mm
- Diameter (mm): 7.9 mm
- Accuracy: ±3 μm
ToolBuy Benefits
- Secure Payments
- Order Tracking (opens in a new tab)
₹1,552 (Incl. of all taxes)
₹1,315 + ₹237 GST (18%)
MRP was MRP ₹1,750
Save 25%
7 Business Days
1
90318000
Download Product LeafletNot available
Download Mitutoyo CatalogueNot available
Download Mitutoyo CatalogueNot available
Highlights
A Mitutoyo precision length standard for accurately setting a micrometer at the start or end of its measuring range. Can also be used for setting other types of continuous-scale measuring instruments at a certain point within the measuring range when wishing to use the narrow-range accuracy capabilities of that instrument.
Please Note that Product may differ eg. colour, size from the product Image displayed on website. Kindly check the specifications provided to make better purchase decision. M.R.P Prices and specifications are subject to change without notice.
Features:
- Used for the zero point setting of outside micrometers.
- Flat and lapped measuring faces.
- Heat insulating handle to prevent expansion due to body temperature
- Supplied in fitted carton Box.
Please Note that Product may differ eg. colour, size from the product Image displayed on website. Kindly check the specifications provided to make better purchase decision. M.R.P Prices and specifications are subject to change without notice.
Specifications
| Length (mm) | 100 mm |
|---|---|
| Diameter (mm) | 7.9 mm |
| Accuracy | ±3 μm |
| Flatness | 0.3 μm |
| Parallelism | 2 μm |
