Motwane 6000 Count TRMS Digital Multimeter With Backlight, M63

Motwane’s true RMS industrial graded Digital Multimeter M63 is specially designed in our research laboratory with stringent manufacturing standards. It has a wide range of applications in power generation, distribution, and transmission along with steel industries, cement industries, mining, power electronics, heavy engineering industries, defense, and aviation sector. M63 is a versatile and high performance industrial grade multimeter that complies with IEC 61010-1-2010, CE, CAT IV 600V safety ratings, and IP 54 protection safety standards. It provides an excellent noise immunity against disturbances from energized power lines. M63 measures AC/DC voltage and current, resistance, capacitance, electronic and electrical frequency, continuity beeper, diode test (2.85 Volt open circuit voltage), and 6000 counts resolutions

Features:

• 6000 counts LCD display with a pleasant white backlight
• AC/DC current range up to 20A
• Resistance, capacitance, diode & continuity measurement facility
• Selectable frequency & duty cycle measurement
• 60 positions analog bar graph for trend indication
• Highly linear readings
• SELECT, RANGE, HOLD/LIGHT, REL, Hz/DUTY
• MAX/MIN function incorporated
• Safety – CE, CAT IV (600V), IP 54, EN 61326-1 & IEC 61010-1
• Robust, rugged & double mold casing.
• Auto Power OFF: After 15 Min., Ideal sleep mode, consumption is 300uA approx. (Can be cancelled by pushing  SELECT key before power on the meter).
• Fuse Protection for ‘mA’ input terminal: 0.75 A/ 0.8 A/ 500V fast blow type ceramic fuse.
• Fuse Protection for 20A input terminal: 20A/ 500V fast blow type ceramic fuse

Application:

• Power Utility
• Industries
• Electrical Contractor
• Telecommunication
• Railway
• Defense

Technical Data:

DC Voltage (Note: Input Impedance 10M Ohm approx)
Range	Resolution	Max. Reading	Accuracy	Overload protection
600mV	0.1mV	600.0mV	±(0.5% + 3)	1050V DC / AC RMS
6V	1mV	6.000V
60V	10mV	60.00V
600V	100mV	600.0V
1000V	1V	1000V	±(0.8% + 3)
AC Voltage (50-500Hz)Trms (Note Input impedance: 10 M Ohm approx. shunted by 60pF approx)
Range	Resolution	Max. Reading	Accuracy	Overload Protection
6V	1mV	6.000V	±(1% + 5)	1050V DC / AC RMS
60V	10mV	60.00V
600V	100mV	600.0V
750V	1V	750V	±(1.2% + 8)
DC’mV’ Range (Input Impedance: ≥1000M Ohm approx.)
Range	Resolution	Max. Reading	Accuracy	Overload Protection
60mV	0.01mV	60.00mV	±(0.5% + 3)	1000V DC / AC rms
600 mV	0.1mV	600.0mV
AC’mV’ Range (50Hz-1KHz) Trms (Input Impedance: ≥1000M Ohm approx.)
Range	Resolution	Max. Reading	Accuracy	Overload Protection
60mV	0.01mV	60.00mV	±(1% + 5)	1000V DC / AC rms
600mV	0.1mV	600.0mV
DC Current Rang (Note: 1.10A for continuous / 2.>10A for 20sec. after 15min. cool down interval)
Range	Resolution	Max. Reading	Accuracy	Overload Protection
60 mA	0.01 mA	60.00 mA	±(1% + 5)	0.75A / 0.8A / 500V DC / AC fuse protection
600 mA	0.1 mA	600.0 mA
6 A	1 mA	6.000 A	20A / 500V DC / AC fuse protection
20 A	10 mA	20.00 A	±(1.2% + 5)
AC Current Range (50Hz-500Hz) Trms (Note: 1.10A for continuous / 2.>10A for 20sec. after 15min. cool down interval)
Range	Resolution	Max. Reading	Accuracy	Overload Protection
60 mA	0.01mA	60.00mA	±(1.2% + 5)	0.75A / 0.8A / 500V DC / AC fuse protection
600 mA	0.1 mA	600.0mA
6A	1 mA	6.000 A	20A / 500V DC / AC fuse protection
20A	10mA	20.00 A	±(1.5% + 5)

Resistance Range (Note: Open Circuit Voltage on 600 - 6M Ohm ranges is 0.62V DC approx. / Open Circuit Voltage on 60M Ohm range is 0.31V DC approx)

Range	Resolution	Max. Reading	Accuracy	Overload protection
600 Ohm	0.1 Ohm	600.0 Ohm	±(0.5% + 3)	1000V DC/AC rms
6 K Ohm	1 Ohm	6.000 Ohm	±(0.5% + 3)
60 K Ohm	10 Ohm	60.00 KOhm	±(0.5% + 3)
600 K Ohm	100 Ohm	600.0 KOhm	±(0.5% + 3)
6 M Ohm	1 K Ohm	6.000 MOhm	±(1% + 5)
60 M Ohm	10 K Ohm	60.00 MOhm	±(3% + 5)

Capacitance Range (Auto Ranging Only) (Note: Setting Time On 4000uf Range Is 40sec. Approx.)

Range	Resolution	Max. Reading	Accuracy	Overload protection
40 nF	0.01 nF	39.99 nF	±(3.0% + 10)	1000V DC/AC rms
400 nF	0.1 nF	399.9 nF	±(3.0% + 10)
4 µF	1 nF	3.999 µF	±(3.0% + 10)
40 µF	10 nF	39.99 µF	±(3.0% + 10)
400 µF	100 nF	399.0 µF	±(3.0% + 10)
4000 µF	1 µF	3999 µF	±(5.0% + 20)

Diode Test:

Range	Resolution	Open Circuit Voltage	Test Current
6V	1mV	≤2.85 V DC	≤1mA approx..

Continuity Test: (Note: Open Circuit Voltage on continuity range is 0.64VDC approx.)

Range	Resolution
600.0 Ohm	0.1 Ohm	Meter Beeps at 60 Ohm

Frequency Ranges (Auto Ranging Only)

Range	Resolution	Max. Reading	Accuracy	Overload protection
10 Hz	0.001 Hz	9.999 Hz	±(0.1% + 3)	1000V DC/AC rms
100 Hz	0.01 Hz	99.99 Hz	±(0.1% + 3)
1 kHz	0.1 HZ	999.9 Hz	±(0.1% + 3)
10 kHz	1 Hz	9.999 KHz	±(0.1% + 3)
100 kHz	10 Hz	99.99 KHz	±(0.1% + 3)
1000 kHz	100 Hz	999.9 KHz	±(0.1% + 3)
10 MHz	1 kHz	9.999 MHz	±(0.1% + 3)

Duty Cycle Measurement

Range	Resolution	Accuracy	Overload Protection
0.1%-99.9%	0.1%	±(0.5% + 3)	1000V DC/AC rms

Package Content:

• Digital Multimeter
• User Manual
• Battery installed
• Fuses
• Carry Bag
