Crystal 150 x 48 x 88 mm Precision Grinding Sine Vice Angular Type, AA - 6141
Roll over the image to zoom in
Key Features
- Product Type: Sine Vice
- Length (mm): 150 mm
- Width (mm): 48 mm
- Height (mm): 88 mm
- Jaw Opening: 0 - 75 mm
ToolBuy Benefits
- Secure Payments
- Order Tracking (opens in a new tab)
₹15,437 (Incl. of all taxes)
₹13,082 + ₹2,355 GST (18%)
MRP was MRP ₹14,220
Save 8%
3 Business Days
1
–
Download Product LeafletNot available
Download Crystal CatalogueNot available
Download Crystal CatalogueNot available
Highlights
- Compound angles easily & quickly set
- Adjustments up to 45 degrees.
- Fixed down jaw-designed sine vice.
- Used for precision measurement, setting of angles, right angle grinding, and light machining.
- Made from high-quality alloy steel.
- Accuracy for squareness, Flatness, & Parallelism is without 0.005mm.
- Angular accuracy within ±5 seconds.
- The Center distance between rollers is within ±0.005mm.
- Material Hardened -60±2 Rc & Tempered.
Please Note that Product may differ eg. colour, size from the product Image displayed on website. Kindly check the specifications provided to make better purchase decision.
Specifications
| Length (mm) | 150 mm |
|---|---|
| Width (mm) | 48 mm |
| Height (mm) | 88 mm |
| Series | AA-614 |
| Jaw Opening | 0 - 75 mm |
| C.D. 'S' in mm Centre Dist | 125 |
