₹2,54,364 (Incl. of all taxes)
₹2,15,563 + ₹38,801 GST (18%)
MRP was MRP ₹3,68,644
Save 31%
3 Business Days
| Objective magnification | Magnification | Measuring Accuracy |
| 0.7X | 6X | ±15µm |
| 1X | 8X | ±15µm |
| 1.5X | 13X | ±9µm |
| 2X | 17X | ±9µm |
| 2.5X | 21X | ±9µm |
| 3X | 25X | ±9µm |
| 3.5X | 30X | ±8µm |
| 4X | 34X | ±8µm |
| 4.5X | 38X | ±7µm |
| Digital Measuring Microscope | 1 Pc |
| 0.5X Auxiliary Objective | 1 Pc |
| Calibration plate | 1 Pc |
| Power adapter | 1 Pc |
| Mouse | 1 Pc |
| 16G USB flash disk | 1 Pc |
| Sensor | 1/2" CMOS |
|---|---|
| Pixel | 2M |
| Resolution | 1920x1080 Pixel |
| Magnification | 6 - 38X |
| Focus distance | 120 mm |
|---|
| View field | 6.4x3.6 - 41.8x23.4 mm |
|---|
| Max workpiece height | 205 mm |
|---|
| Frame rate | 60fps |
|---|
| Output | USB/HDMI/LAN |
|---|
| Power supply | Power adapter |
|---|
| Dimensions (L x W x H) | 305 x 405 x 530 mm |
|---|
