₹1,60,656 (Incl. of all taxes)
₹1,36,149 + ₹24,507 GST (18%)
MRP was MRP ₹2,23,133
Save 28%
3 Business Days
| Main unit | 1 Pc |
| Calibration plate | 1 Pc |
| Power adapter | 1 Pc |
| Mouse | 1 Pc |
| 16G USB flash dish | 1 Pc |
| Objective magnification | Magnification | Measuring Accuracy |
| 0.7X | 12X | +/- 9um |
| 1X | 17X | +/- 9um |
| 1.5X | 26X | +/- 8um |
| 2X | 35X | +/- 7um |
| 2.5X | 43X | +/- 7um |
| 3X | 51X | +/- 7um |
| 3.5X | 60X | +/- 6um |
| 4X | 68X | +/- 6um |
| 4.5X | 77X | +/- 5um |
| Sensor | 1/2" CMOS |
|---|---|
| Pixel | 2M |
| Resolution | 1920x1080 |
| Magnification | 12~77X |
| Focus distance | 100mm |
| View field | 2.7x1.9~17.5x11.9mm |
| Max workpiece height | 60mm |
|---|
| Frame rate | 60fps |
|---|
| Output | USB/HDMI |
|---|
| Power supply | Power adapter |
|---|
| Dimensions (L x W x H) | 610 x 610 x 660 mm |
|---|
