Double insulation per IEC / UL / EN61010-1 2nd Ed., 3.0, IEC / EN61010-2-030 Ed. 1.0, IEC / EN61010-2-033 Ed. 1.0, IEC / UL / EN61010-031 Ed. 1.1 & CAN / CSA-C22.2 No.61010-1-12 Ed. 3.0 to CAT III 1000V AC & DC and CAT IV 600V AC & DC.
Features & Benefits:
- Basic DC Voltage Accuracy: 0.08%
- 50ms record MAX-MIN readings at fast 20/second measurement mode
- 0.8ms Crest (instantaneous Peak-HOLD)
- Data Hold & Range- Hold
- Backlighted Display
- Autoranging
- MAX-MIN readings
- Fire retarded casing.
- Diode & Continuity Test
- Type-K Temperature
- Audible & Visible BeepJack Input warning against improper plug in
- Relative-Zero offset mode
- Zoom 5x Analog pointer at 60/s
- Auto power off
- PC Interface (BRUA-85Xa) (Optional)
Safety:
- E. M. C: Meets EN61326-1:2013
- In an RF field of 3V/m: The capacitance function is not specified
- Other function ranges: Total Accuracy = Specified Accuracy + 100 digits
- Performance above 3V/m is not specified.
- Transient Protection: 8kV lightning surge (1.2/50µs)
- Terminals (to COM) Measurement Category V/ mAµA / A: CAT III 1000 Volts AC & DC, and CAT IV 600 Volts AC & DC
- Overload Protection (µA & mA): 0.44A/1000V, IR 10kA , F fuse
- Overload Protection (A): 11A/1000V, IR 20kA, F fuse
- Overload Protection (V): 1100V DC/AC rms
- Overload Protection (mV, Ω & Others): 1000V DC/AC rms
Package Content:
- Test leads (pair)
- Holster, Battery
- User's Manual
- Bkp60 banana plug K Type Thermocouple
