- Beep-Jack Audible & Visible Input Warning
- BeepLit Continuity Tester
- Relative Zero Mode
- Crest (Peak Hold) MAX/MIN Readings
- VFD Function
- 61 Segment Analog Bar-graph
- Display Hold
- Record MAX / MIN
Features & Benefits:
- DC Voltage Basic Accuracy 0.09%
- Dual digital display AC + Hz readings
- Selectable 6,000 & 20,000 counts resolution.
- Nominal 5/sec Fast Measurements, Fully Auto-Ranging
- Paper-White Back-lighted LCD Display.
- High update record Max/Min readings
- Rugged fire retarded casing with battery & fuse access door.
- Replaceable protective holster with probe holders & tilt-stand.
- Diode & Continuity Test
- Auto Power Off
Safety:
- Double insulation per IEC/UL/EN61010-1 Ed., 3.0, IEC/UL/EN61010-2-030 Ed. 1.0, IEC/UL/ EN61010-2-033 Ed. 1.0, IEC/UL/EN61010-031 Ed. 1.1 & the corresponding CAN/CSA-C22.2 regulations to measurement CAT III 1000V AC & DC & Category IV 600V AC & DC.
- Transient Protection: 8 kV (1.2/50µs surge)
- Overload Protection: µA & mA - : 0.4A/1kV DC/AC rms, IR 30kA, F Fuse or better / A: 11A/1kV DC/AC rms, IR 20kA, F Fuse or better / V: 1100V DC/AC rms / mV, ohms & Others : 1000V DC/AC rms
- EMC: Meets EN61326-1:2013 In an RF field of 3V/m : Total Accuracy = Specified Accuracy + 150 dgts Performance above 3V/m is not specified
Package Content:
- Test lead pair
- Holster
- Battery installed
- User Manual
- BKP60 banana plug type-K Thermocouple
