₹73,941 (Incl. of all taxes)
₹62,662 + ₹11,279 GST (18%)
7 Business Days
1
–
Please Note that Product may differ eg. colour, size from the product Image displayed on website. Kindly check the specifications provided to make better purchase decision. M.R.P Prices and specifications are subject to change without notice.
| Max. Input Voltage | 10kV (DC), 7kVrms (AC), 20kV (PEAK) |
|---|---|
| Bandwidth | 40MHz (±3dB) |
| Attenuation Ratio | x1000 |
| Input Impedance | 100M Ohm, 3pF |
| Rise Time | <9ns |
| Cable Length | 2m |
| Compensation Range | 15 to 30pF |
| Operating Temperature | 0 - 50°C |
| Storage Temperature | -20 to +70°C |
| Temperature Coefficient | Less than 200ppm/°C |
| Accuracy | ±6% (DC Volts) |
| Altitude | Up to 4600 Meters (15.000 ft) |
| Humidity | Up to 80% relative humidity at +40°C |
| Dimensions (L x W x H) | 350 x 75 x 75 mm |
| Order Number | 15010 |
