₹25,700 (Incl. of all taxes)
₹21,780 + ₹3,920 GST (18%)
7 Business Days
1
–
Please Note that Product may differ eg. colour, size from the product Image displayed on website. Kindly check the specifications provided to make better purchase decision. M.R.P Prices and specifications are subject to change without notice.
| Max. Input Voltage (DC) | 40kV |
|---|---|
| Max. Input Voltage (AC) | 28kV RMS (0 - 300Hz) |
| Attenuation Ratio | x1000 @ 10MOhm / x2000 @ 1MOhm |
| Input Impedance | 1000M Ohm |
| Bandwidth | 300Hz (-3dB) |
| Cable Length | 1 Mtr |
| Altitude | Up to 4600 meters (15.000 ft) |
| Temperature Coefficient | Less than 200ppm/°C |
| Operating Temperature | 0°C to +50°C |
| Storage Temperature | -20°C to +70°C |
| Humidity | Up to 80% relative humidity at +40°C |
| Order Number | 15001 |
| Dimensions (L x W x H) | 350 x 75 x 75 mm |
