- AutoV (LoZ)
- BeepJackT on mAmA / A terminals
- BeepLitTM Continuity
- Auto-ranging MAX / MIN / AVG Record
- Backlighted LCD
- Auto-ranging Relative Zero mode
- Display Hold
- EF-Detection (NCV)
- VFD
- Update Rate: 3-5/6 digits (Max 5 per second nominal) / 60 Segment Bar-graph (40 per second max)
- Relative Humidity: MMaximum relative humidity 80% for temperature up to 31°C decreasing linearly to 50% relative humidity at 50°C
- Temperature Coefficient: Nominal 0.15 x (specified accuracy)/°C @ (-10 °C ~ 18°C or 28°C ~ 50°C), or otherwise specified
Safety:
- Certified per IEC/UL/EN61010-1 Ed. 3.1, IEC/UL/ EN61010-2-033 Ed. 2.0, IEC/UL/EN61010-031 Ed. 2.0 and the corresponding CAN/CSA-C22.2 regulations to Measurement. Categories: CAT II 1000V, CAT III 600V and CAT IV 300V AC & DC
E. M. C.:
- Meets EN61326-1
- In an RF field of 3V/m: Temperature function is not specified.
- Ohm function: Total Accuracy = Specified Accuracy + 15 digits
- Other functions: Total Accuracy = Specified Accuracy
- Performance above 3V/m is not specified
Overload Protections:
- mA & mA: 0.63A/1000V DC/AC rms, IR 30kA, F fuse; or better A: 11A/1000V DC/AC rms, IR 20kA, F fuse; or better V & AutoV: 1100V DC/AC rms mV, Ohm & others: 1000V DC/AC rms
Package Content:
- Digital Multimeter
- Test lead pair
- Batteries installed
- User's manual
- BKP60 banana plug type-K thermocouple
