Double insulation per IEC/UL/EN61010-1 Ed. 3.0, IEC/UL/EN61010-2-030 Ed. 1.0, IEC/UL/EN61010-2-033 Ed. 1.0, IEC/UL/EN61010-031 Ed. 1.1 & the corresponding CAN/CSA-C22.2 regulations to measurement CAT II 1000V, CAT III 600V and CAT IV 300V AC & DC.
Features & Benefits:
- VFD V & Hz Function
- EF-Detection (NCV)
- Paper White Backlight Display
- Auto-ranging Relative Zero Mode
- Auto Power Off
- Low Battery Indication
- Display Hold
- Diode & Continuity Test
- Type-K Temperature
- BeepLit Continuity, Features Audible Beep & Visible Backlight Effects
- Beep-Jack Input warning on mAmA/A terminals plug-in
- Auto-ranging MAX/MIN/AVG record
- AutoV LoZ Feature. Automatic DC & AC1000V Selection with Low Initial Impedance to drain ghost voltages.
- Rugged Fire retarded casing.
Safety:
- E. M. C: Meets EN61326-1:2006
- In an RF field of 3V/m: Ohm function - Total Accuracy = Specified Accuracy + 15 digits
- Other function ranges: Total Accuracy = Specified Accuracy
- Performance above 3V/m is not specified.
- Transient Protection: 6.0kV lightning surge (1.2/50µs)
- Terminals (to COM) Measurement Category V/ mAmA / A: CAT II 1000 Volts and CAT III 600V and CAT IV 300 Volts AC & DC
- Overload Protection (µA & mA): : 0.4A / 1000V DC/AC rms, IR 30kA, F fuse
- Overload Protection (A): 11A / 1000V DC/AC rms, IR 20kA, F fuse
- Overload Protection (V & Auto V): 1100V DC/ACrms
- Overload Protection (mV, Ω & Others): 1000V DC/AC rms
Package Content:
- Test leads pair
- Carrying Case
- Batteries installed
- User's Manual
- BKP60 banana plug type-K Thermocouple
