- 500,000 counts high-resolution stable reading mode.
- 20kHz Bandwidth voltage function
- Record MAX, MIN and MAX-MIN readings.
- Crest (Instantaneous Peak Hold) MAX, MIN, MAX- MIN readings.
- Relative zero mode.
- dBm readings.
- % 4 -20mA loop current readings.
- High noise rejection filtered Line Level Frequency mode.
- Line Level Frequency with 4 Trigger Levels.
- HBC Fuse Protection
Features & Benefits:
- DC Voltage Basic Accuracy 0.03%
- Fully Autoranging
- Backlighted display.
- Fast Data Measurement 5/sec
- Data Hold function
- Diode Test & Duty Cycle
- Audible & Visible input warning
- Auto Power Off
Safety:
- Double insulation per IEC/UL/EN61010-1Ed.3.0, IEC / EN61010-2-030 Ed. 1.0, IEC / EN61010-2-033 Ed. 1.0, IEC/UL/EN61010-031 Ed. 1.1 and CAN/ CSA-C22.2 No. 61010-1-12 Ed. 3.0 to CAT III 1000V AC & DC & CAT IV 600V AC & DC.
- Transient Protection: 8 kV (1.2/50µs surge)
- Terminals (to Com) Measurement Category: V/A/mAµA - Category III 1000V AC & V DC & CAT IV 600V AC & V DC
- Overload Protection: µA & mA: 0.44A/1000V DC/AC rms, IR10kA, F Fuse A: 11A/1000V DC/AC rms, IR 20kA, F Fuse V: 1100V DC/AC rms mV, W & Others :1000V DC/AC rms
- EMC: Meets EN61326-1:2006(EN55022, EN61000-3-2, EN61000-3-3, EN61000-4-2, EN61000-4-3, EN61000-4-4, EN61000-4-5, EN61000-4-6, EN61000-4-8, EN61000-4-11) In an RF field of 3V/m: Capacitance function is not specified Other function ranges: Total Accuracy = Specified Accuracy +100 digits Performance above 3V/m is not specified
Package Content:
- Test Leads pair
- Holster
- Battery installed
- User Manual
