| Measuring Travel | ± 1 mm |
|---|---|
| Total Travel | 2 mm |
| Linearity | ± 0.3% |
| Repeatability | 0.5 μm |
| Measuring force | 0.25 N |
| Pre-travel | Fixed |
| Environmental Protection (IEC 529) | IP 50 |
| Cable support spring | N/A |
| Reference temperature | 20° C |
| Cable | PVC |
| Connection adaptor | 5-pin, Male DIN plug (240°) |
| Application | Low Measuring Force |
| Plunger guide | Parallel Leaf spring |
| Contact Tip | 9 mm long stylus having M1.6 threads & Ø 2 mm tungsten carbige ball tip |
